DualDiff: A Dual-Branch Diffusion Model for Multi-View and Video-Level Driving Scene Generation

DualDiff is a novel dual-branch conditional diffusion framework tailored for realistic and temporally consistent driving scene generation, capable of integrating multi-view semantics and video dynamics for high-fidelity outputs.

🗞️ Project News

[2025-01-28] ✨ DualDiff accepted to ICRA 2025.
[2025-03-07] 🚀 DualDiff+ under review with extended video-level consistency modeling.
[2025-05-07] 📂 DualDiff image generation code officially open-sourced.

🧠 Abstract

Autonomous driving requires photorealistic, semantically consistent, and temporally coherent simulation of driving scenes. Existing diffusion-based generation models typically rely on coarse inputs such as 3D bounding boxes or BEV maps, which fail to capture fine-grained geometry and semantics, limiting controllability and realism.

We introduce DualDiff, a dual-branch conditional diffusion model designed to enhance both spatial and temporal fidelity across multiple camera views. Our framework is characterized by the following contributions:

Occupancy Ray-shape Sampling (ORS): A geometry-aware conditional input that encodes both foreground and background spatial context in 3D, providing dense and structured guidance.
Foreground-Aware Masking (FGM): A denoising strategy that explicitly attends to the generation of small, complex, or distant objects in the scene.
Semantic Fusion Attention (SFA): A dynamic attention mechanism that fuses multi-source semantic conditions, filtering irrelevant signals and enhancing scene consistency.
Reward-Guided Diffusion (RGD): A video-level optimization framework that leverages task-specific reward signals to guide generation toward temporal and semantic coherence.

Results: DualDiff outperforms prior methods on the nuScenes dataset, achieving:

A 4.09% FID improvement over the best previous method.
A 4.50% gain in vehicle mIoU and 1.70% in road mIoU for downstream BEV segmentation.
A 1.46% improvement in foreground mAP for BEV 3D object detection.

🎬 Visual Examples

Generated scenes by DualDiff+:

generated_video

🔧 Method Overview

DualDiff consists of a dual-stream conditional UNet where foreground and background features are processed independently and merged through residual learning.

Key architectural components:

ORS Module: Injects fine-grained 3D-aware condition priors derived from occupancy ray-shape projections.
SFA Mechanism: Enhances multimodal fusion using cross-attention and semantic importance weighting.
Two-Stage Training Strategy:
- Stage 1: Spatio-temporal learning via ST-Attn and temporal attention.
- Stage 2: Fine-tuning using Reward-Guided Diffusion (RGD) and LoRA to optimize for generation quality and efficiency.

Framework

🚀 Quick Start

1. Clone Repository

git clone --recursive https://github.com/yangzhaojason/DualDiff.git

2. Environment Setup

conda create -n dualdiff python=3.8
conda activate dualdiff
pip install torch==1.10.2+cu113 torchvision==0.11.3+cu113 --extra-index-url https://download.pytorch.org/whl/cu113
pip install -r requirements/dev.txt

Additional setups:

cd third_party/xformers && pip install -e .
cd ../diffusers && pip install -e .
cd ../bevfusion && python setup.py develop

3. Data Preparation

Download nuScenes dataset: link

Structure:

data/nuscenes/
├── maps
├── mini
├── samples
├── sweeps
├── v1.0-mini
└── v1.0-trainval

Generate annotations:

python tools/create_data.py nuscenes --root-path ./data/nuscenes --out-dir ./data/nuscenes_mmdet3d_2 --extra-tag nuscenes

Place all .pkl annotation files as instructed (see README).
Download occ projection from Google Driver and extract the file to the root directory.

4. Pretrained Weights

Obtain SDv1.5 weights from Huggingface
Follow MagicDrive setup instructions.

🏋️ Training & Evaluation

Training

accelerate launch --mixed_precision fp16 --gpu_ids all --num_processes {num_gpu}   tools/train.py +exp={exp_config_name} runner=8gpus   runner.train_batch_size={train_batch_size}   runner.checkpointing_steps=4000 runner.validation_steps=2000

Evaluation

accelerate launch --mixed_precision fp16 --gpu_ids all --num_processes {num_gpu}   perception/data_prepare/val_set_gen.py resume_from_checkpoint=magicdrive-log/{generated_folder}   task_id=dualdiff_gen fid.img_gen_dir=./tmp/dualdiff_gen +fid=data_gen   +exp={exp_config_name} runner.validation_batch_size=8

FID / FVD Metrics

python tools/fid_score.py cfg   resume_from_checkpoint=./pretrained/SDv1.5mv-rawbox_2023-09-07_18-39_224x400   fid.rootb=tmp/dualdiff_gen

📈 Quantitative Results

Visual and numerical evaluation of DualDiff on nuScenes:

Results

📚 Citation

@article{yang2025dualdiff+,
  title={DualDiff+: Dual-Branch Diffusion for High-Fidelity Video Generation with Reward Guidance},
  author={Yang, Zhao and Qian, Zezhong and Li, Xiaofan and Xu, Weixiang and Zhao, Gongpeng and Yu, Ruohong and Zhu, Lingsi and Liu, Longjun},
  journal={arXiv preprint arXiv:2503.03689},
  year={2025}
}

@inproceedings{li2025dualdiffdualbranchdiffusionmodel,
      title={DualDiff: Dual-branch Diffusion Model for Autonomous Driving with Semantic Fusion},
      author={Haoteng Li and Zhao Yang and Zezhong Qian and Gongpeng Zhao and Yuqi Huang and Jun Yu and Huazheng Zhou and Longjun Liu},
      booktitle={IEEE International Conference on Robotics and Automation (ICRA)},
      year={2025},
      pages={},
      organization={IEEE},
      address={},
      url={https://arxiv.org/abs/2505.01857 },
}

For full details, visit the project page or the GitHub repository.
